Full Specification

Container 2-Bedroom House with Wheels – Portable & Durable Home

---

1. Product Overview

The Container 2-Bedroom House with Wheels is a modern, portable housing solution designed for mobility, durability, and comfortable living. Built on a reinforced steel container frame and mounted on a heavy-duty wheel chassis, this home combines the strength of container construction with the flexibility of relocation.

It is ideal for residential use, workforce accommodation, remote housing, temporary housing, vacation homes, site offices, and emergency shelters. The unit is factory-built and delivered as a near-complete structure, allowing for fast installation and immediate use.

---

2. Dimensions & Capacity

Standard Dimensions (Customizable)

• Length: 9.0 m – 12.0 m

• Width: 2.5 m – 3.0 m

• Height: 2.8 m – 3.2 m

• Total Floor Area: Approx. 30 – 40 m²

Weight

• Net Weight: Approx. 6 – 10 tons (depending on size and configuration)

---

3. Structural System

Main Frame

• High-strength galvanized steel container frame

• Reinforced corner castings for lifting and transportation

• Anti-corrosion and anti-rust surface treatment

Load & Durability

• Designed for long-term use and frequent relocation

• High resistance to wind, rain, and harsh environments

• Suitable for various terrain conditions

---

4. Wheel & Chassis System

• Heavy-duty steel trailer chassis

• Multi-axle wheel system for load balance

• Industrial-grade tires suitable for road transport

• Detachable or fixed wheel system (optional)

• Front towing hitch for easy relocation

---

5. Exterior Construction

• Wall Panels: Insulated sandwich panels or steel composite panels

• Roof: Integrated insulated steel roof with waterproof membrane

• Exterior Finish: Powder-coated steel or aluminum panels

• Weatherproofing: Fully sealed against rain, dust, and moisture

---

6. Insulation & Thermal Performance

• Wall Insulation: Polyurethane (PU), EPS, or Rock Wool

• Insulation Thickness: 50 mm – 100 mm

• Thermal Efficiency: Suitable for hot, cold, and humid climates

• Sound Insulation: Reduced noise transmission for indoor comfort

---

7. Doors & Windows

Windows

• Double-glazed insulated glass

• Aluminum alloy frames with thermal break

• Optional large or panoramic windows

Doors

• Insulated steel or aluminum main door

• Interior room doors (PVC or composite wood)

---

8. Interior Layout (2-Bedroom Design)

Room Configuration

• Living Area: Central open-plan living space

• Kitchen Area: Compact kitchen zone

• Bedroom 1: Master bedroom

• Bedroom 2: Secondary bedroom

• Bathroom: Fully enclosed bathroom

• Storage: Built-in cabinets and wardrobes

---

9. Interior Finishes

• Flooring: SPC, vinyl, laminate, or engineered wood

• Walls & Ceiling: Decorative panels or PVC boards

• Lighting: Energy-efficient LED ceiling lights

• Color Scheme: Customizable interior finishes

---

10. Kitchen Specification

• Kitchen countertop with sink

• Upper and lower storage cabinets

• Space reserved for refrigerator and cooker

• Optional built-in appliances

---

11. Bathroom Specification

• Shower area with waterproof wall panels

• Toilet (standard or water-saving type)

• Wash basin with mirror

• Exhaust ventilation system

• Hot and cold water plumbing

---

12. Electrical System

• Voltage: 110V / 220V / 240V (customizable)

• Pre-installed concealed wiring

• Distribution box with safety breakers

• Power outlets and light switches in all rooms

• Interior and exterior LED lighting

---

13. Plumbing System

• Fresh water inlet connection

• Drainage and sewage outlet

• PPR or PVC piping

• Compatible with municipal water, septic tank, or water storage systems

---

14. Climate Control

• Pre-installed air-conditioning position or unit

• Optional heating system (electric or floor heating)

• Ventilation for moisture and heat control

---

15. Mobility & Transportation

• Designed for truck or tractor towing

• Integrated lifting points for crane handling

• Quick relocation without structural damage

• Suitable for temporary or semi-permanent placement

---

16. Installation & Foundation

• Installation Time: 1–2 days

• Foundation Options:

  • Concrete pads

  • Steel supports

  • Adjustable footings

No permanent foundation required in most cases.

---

17. Safety & Performance

• Fire-resistant wall and insulation materials (optional)

• Anti-slip flooring

• Secure door and window locking systems

• Weather-resistant electrical and plumbing design

---

18. Customization Options

• Layout modification

• Size and length extension

• Solar power preparation

• Smart home system integration

• Enhanced insulation packages

• Exterior color and branding

---

19. Applications

• Residential housing

• Workforce and staff accommodation

• Construction site housing

• Remote area living

• Emergency and disaster relief housing

• Rental and vacation homes

---

20. Service Life & Maintenance

• Designed Lifespan: 20 – 50+ years

• Low maintenance steel structure

• Easy replacement of modular components

---

21. Specification Summary

• Type: Container House with Wheels

• Bedrooms: 2

• Floor Area: 30 – 40 m²

• Structure: Galvanized steel container frame

• Mobility: Trailer chassis with wheels

• Installation: Fast, portable, plug-and-use

• Durability: Weather-resistant and long-lasting
